Expanded metal is made from 0.1mm-4mm thickness metal plate by uniformly slit and stretched,forming diamond opening in the metal sheet. For its uniform small openings and flat surface,it is used for battery, headphones and speaker grille, building,wall and other filtration support etc.

Expanded Metal Application

Facade cladding materials in building and ornament construction

Civil engineering, building walls

Cooling hood and mechanical transmission shield mesh

Sports venues fence, road green belt protection mesh

for the tanker car pedal mesh and many other usages

Oil drilling platform, ship platform, platform, handrails, walkways, cabin ceiling

Expanded Metal Material

Stainless steel plate: 201, 202, 304, 304L, 316, 316L, 321, 430

Low carbon steel plate : Q235,Q295

Aluminium pure aluminum plate, aluminum alloy plate

Copper plate, brass plate

Nickel plate

Titanium plate

Expanded Metal Specification

Diamond Hole Expanded Metal Sheets

Plate thickness 0.1mm to 6mm

Strand 0.1mm to 6mm

Hole size 1x0.5mm to 100x50mm

The details please check the Diamond Hole Expanded Metal Sheets Specifications Table.(PDF)

Hexagonal Hole Expanded Metal Mesh

Plate thickness 0.4mm to 6mm

Strand 0.5mm to 6mm

Hole size 3x3mm to 100x38mm

The details please check the Hexagonal Hole Expanded Metal Mesh Specifications Table.(PDF)

Expanded Metal Form Types

Expanded metal is generally formed in standard(raised) type or flattened type.

Standard Expanded Metal is directly slit and stretched by punching machines without other processing,The strand width and bond come in with an angle with the plate surface. This kind structure increase the strength and hardness of expanded metal,it also brings better anti-slipping and reinforcing performance.

Flattened expanded metal is formed by flattening process based on standard expanded metal. Its strand width and bond are in the same horizontal plane with plate surface. Compared with standard expanded metal,the plate thickness will be thinner and hole size will be larger.

How to order expanded metal

Material eg. Grade 304

Plate thickness eg.1mm

LWD eg. 20mm

SWD eg. 10mm

Width eg.1m

Length eg. 1m

Expanded Metal Packing

When packing,expanded metal appears in roll type and flat type.They are packed in wooden pallets generally.Each pallet load 0.5 ton-1 tons and wrapped with plastic film.
