Wire Mesh Demister Pads Processing

Mesh demister pads are made up knitted gauze pad and support grid of two parts. It is a gas-liquid separator , when the vapor through demister pads it can remove the water mist .The primary function of mist eliminator is to collect water droplets and oil mist from a compressed air system and divert the liquid to an appropriate drain. Mist is formed due to the contact of liquid with gas and separation of diameter greater than 3um ~ 5um droplets .

Mesh Demister Pads Material

Stainless steel: 201, 202, 304, 304L, 316, 316L, 321, 430

Nickel: nickel, nickel alloy2080, Monel400, Monel600

PP: Polypropylene

PE: Polyethylene

Wire Mesh Demister Pads Types & Specifications

Round Shape

Diameter 300 mm to 5200 mm

Thickness 100mm and 150mm

Rectangular Shape

Size 600x200mm to 6000x800mm

Thickness 100mm to 300mm

Drawer Shape

Diameter 300mm to 5000mm

Thickness 100mm and 150mm

The details please check the Mist Eliminators Specifications Table.(PDF)

Mesh Demister Benefits

Efficient coalescing material

Prevent loss of valuable product

High efficiency with low pressure drop

Easy to install in all process equipment

Eliminates rust and corrosion

Protects downstream equipment

Increase the life of pneumatic equipment

Reduced environmental contamination

Wire Mesh Demister Pads Application

Vacuum Tower and Evaporator

Knockout Drums and Separators

Gas Separator Vessels

Distillation Column

Sulfuric acid/oleum

Plasticizer & Sulphonation

Hydrochloric acid &Nitric acid

Ammonium nitrate&Incinerators

How to Order Wire Mesh Demister Pads

Material eg. Grade 304

DN eg. 600mm

Thickness eg.150mm

Frame : with Frame below and up

Mesh Demister Pads Packing

Demister Pads should be packed firmly and securely. When packing, demister pads are appears in blocks.They are wrapped with plastic film and outside with wooden cases or wooden pallets.
